| - ELECTRICAL SPECIFICATIONS - |
| Frequency Range |
3.2768 to 85.000MHz |
| Operating Temperature Range |
-10 to 60℃(STD), -20 to 70℃, or please specify |
| Storage Temperature Range |
-40 to +85℃ |
| Frequency Tolerance (at 25℃) |
±15, ±30, ±50ppm (STD),or please specify |
Frequency stability
Over Operating Temperature Range |
±30, ±50(STD), ±100ppm
See table 1 in page 1 |
| Load Capacitance(CL) |
18pF(STD), Custom CL ≥ 10pF or Series Resonant |
| Equivalent Series Resistance(ESR) |
3.2768~85.000MHz, 30Ωmax~150Ωmax,
See table 2 in page 1 |
| Drive Level |
100㎼(1000㎼ max) |
| Shunt Capacitance(CO |
7.0pF max |
| Aging(at 25℃) |
±5.0ppm / year max |
| Insulation Resistance |
500Ω min. at 100VDC |
